MATERIAL: Eye wash main body is made of 304 stainless steel
SHOWER VALVE: 1″ 304 stainless steel ball valve
EYE WASH VALVE: 1/2″ 304 stainless steel ball valve
SUPPLY: 1 1/4″ FNPT WASTE: 1 1/4″ FNPT
EYE WASH FLOW: ≥11.4 L/Min, shower flow≥75.7 L/Min HYDRAULIC PRESSURE: 0.2MPA-0.6MPA
ORIGINAL WATER: Drinking water or filtered water
USING ENVIRONMENT: Places where has hazardous substance splashing, such as chemicals, hazardous liquids, solid, gas and so on.
SPECIAL NOTE: 1. If the acid concentration is too high, recommend to use 316 stainless steel.
- When using ambient temperature below 0°C, use antifreeze eye wash.
- The eye wash & shower is made of high quality 304 stainless steel.
- Can install anti-scalding device to avoid the media temperature is too high in the pipe after the sun exposure and cause user scalding. The
standard anti-scalding temperature is 35°C. Standard: ANSI Z358.1-2014
