The main pipe fittings and valves are made of high-quality 304 stainless steel. The yellow ABS eyewash bowl is equipped with a transparent dust cover.
The dust cover is linked with the eyewash valve. Open the dust cover, the eyewash starts the water flow, and close the dust cover to stop the water flow.
There is no external hand push.
HEAD: 10″ 304 stainless steel
EYE WASH NOZZLE: Diameter 1″ stainless steel rotating nozzle
SHOWER VALVE: 1″ 304 stainless steel ball valve EYE WASH VALVE: 1/2″ 304 stainless steel ball valve SUPPLY: 1 1/4″ FNPT WASTE: 1 1/4″ FNPT
EYE WASH FLOW：≥11.4 L/Min, SHOWER FLOW：≥75.7 L/Min HYDRAULIC PRESSURE: 0.2MPA-0.6MPA
ORIGINAL WATER: Drinking water or filtered water
USING ENVIRONMENT: Places where has hazardous substance splashing, such as chemicals, hazardous liquids, solid, gas and so on.
SPECIAL NOTE:If the acid concentration is too high, recommend to use 316 stainless steel. When using ambient temperature below 0°C, use antifreeze
eye wash. Can install anti-scalding device to avoid the media temperature is too high in the pipe after the sun exposure and cause user scalding. The
standard anti-scalding temperature is 35°C.
Standard: ANSI Z358.1-2014
